Square D
SQUARE D XUC-8AKSNM12 PHOTOELECTRIC SENSOR, DIFFUSE, 12 TO 24VDC
SQUARE D XUC-8AKSNM12 PHOTOELECTRIC SENSOR, DIFFUSE, 12 TO 24VDC
$11780
Save $18.30
Request Special Pricing
Couldn't load pickup availability
Product information
Photoelectric Sensor, Shape Rectangular, Sensing Method Diffuse, Operation Mode Selectable Light On/Dark On, Power Requirement 12 to 24VDC, Circuit Type NPN/PNP, Electrical Connection 4-Pin M12 Male Connector, Max. Sensing Distance 1200mm, Length 112.00mm, Max. Load Current 100mA, Response Time 1.0 msec, Operating Frequency 500 Hz, Width 45.00mm, Depth 44.00mm, NEMA Rating 3, 4, 4X, 6, 6P, 12, 13, IP Rating 67, Body Material Polycarbonate, Light Source Infrared LEDFeatures:
- Electrical Connection: 4-Pin M12 Male Connector
- Features: Reverse Polarity, Overload and Short Circuit Protection
- Sensing Method: Diffuse
- Electrical Connection: 4-Pin M12 Male Connector
- Photoelectric Sensor
- Photoelectric Sensor, Shape Rectangular, Sensing Method Diffuse, Operation Mode Selectable Light On/Dark On, Power Requirement 12 to 24VDC, Circuit Type NPN/PNP, Electrical Connection 4-Pin M12 Male Connector, Max. Sensing Distance 1200mm, Length 112.00mm, Max. Load Current 100mA, Response Time 1.0 msec, Operating Frequency 500 Hz, Width 45.00mm, Depth 44.00mm, NEMA Rating 3, 4, 4X, 6, 6P, 12, 13, IP Rating 67, Body Material Polycarbonate, Light Source Infrared LED
Color: Blue
Condition: New
Dims: -Inches x -Inches x -Inches (Length Width Height)
Model: XUC-8AKSNM12
Package quantity: 1
VWA: 24-Volt
